Small Parts Counter U-60B (1-25mm)

The Small Parts Bulk Counter U60B is a tabletop bulk counting solution for a wide range of small objects. The system incorporates patented counting technology that delivers 100% accuracy levels while reaching speeds that are similar to weighing systems. The Small Parts Bulk counting machine U60B is an ideal platform for automated processes such as packaging and inventory management that requires exact quantities.



All the counting data is saved and can be easily retrieved for analysis and reporting purposes. With the Small Parts Bulk Counter U60B, companies benefit from enhanced and real-time product control achieved simply with the click of a button. The results are consistent and repeatable, without the variability associated with scales, manual counting or other counting methods.


The system is ideal for small, high-value objects produced by injection molding, metal lathing, and other intricate processes. It easily handles objects with complex shapes, including the open-shaped items often found in the aerospace, defense, medical, electronic, automotive, hardware, and other industries.



Main Features:

  • 99.9% accuracy
  • Parts size range: 1mm-25mm
  • One-time setup per part
  • Object versatility: one system can count numerous object types
  • Machine stops count at a designated number
  • Works with difficult objects
  • User-friendly interface
  • Counting data is saved and easily retrieved
  • Industry 4.0 compatibility



Features

Object versatility: one system can count numerous object types

Minimal mechanical adjustments when changing objects

Low maintenance and easy to clean

Various bowl feeder options

Count rate: up to 200 objects per second


Technical Specifications

• Voltage: 115 / 230 VAC, 1 phase
• Frequency: 50/60 Hz
• Power consumption: 250 W
• Circuit breaker rate: Minimum 10 A slow-blow
• Dimensions (cm): (W) 71 x (D) 47 x (H) 86 – According to B type
• Weight: ± 72 kg



Optional Equipment

• Barcode scanner
• RS232 Interface for scales
• RS232 Interface for label printer
• Foot pedal
